    Recessed LED down light prices - cob 30w led down light supply

    Ask Lasest Price
    Brand Name : Sourcechip
    Model Number : SC-DLB030W01
    Certification : CE, FCC, RoHS, UL
    Price : $21.69/piece
    Delivery Time : 7-10 working days
    Payment Terms : We accept PayPal, T/T, L/C,Western union, Escrow etc .If need further detail, Please feel free to co
    • Product Details
    • Company Profile

    Recessed LED down light prices - cob 30w led down light supply

    Recessed LED down light prices - cob 30w led down light supply
    Dongguan Sourcechip Opto-electrical Tech Co.,Ltd. is a production and sales, research and development in one of the LED lamps Chinese enterprises. We produce cob 30w led down light go through a rigorous selection, production technology, performance testing and other processes. In order to ensure the quality of the cob 30w led down light. Its properties are as follows. If you have any questions about this cob 30w led down light, you can contact us by e-mail.


    xinxinlong001
    Dongguan Sourcechip Opto-electrical Tech Co.,Ltd.
    Sourcechip cob 30w led down light Tel: +86-769-81608082
    Sourcechip cob 30w led down light Fax: +86-769-81608083
    Sourcechip cob 30w led down light Contact E-mail:
    Sourcechip cob 30w led down light website 1:
    Sourcechip cob 30w led down light website 2:
    Sourcechip cob 30w led down light Address: No.2 Min Yi Road, Wusha Community, Chang'an Town, Dongguan, Guangdong, China

    1.LED DownlightDetails

    Recessed LED down light prices - cob 30w led down light supplyRecessed LED down light prices - cob 30w led down light supplyRecessed LED down light prices - cob 30w led down light supplyRecessed LED down light prices - cob 30w led down light supply


    2.Product material

    Lamp body

    Diffusive lampshade

    light source

    Driver

    Finish

    aluminum alloy

    Light transmittance≥85%

    COB

    wide Input driver

    EMC approved

    white/black


    3. Specification

    Model No.

    SC-DLB030W01-30

    SC-DLB030W01 -40

    SC-DLB030W01 -60

    Rated power

    26W

    Consume power

    30±2W

    Input Voltage

    AC 100-240V

    Output Voltage

    32-42V

    Input current

    720mA±5%

    Efficiency

    ≥85%

    Cutout

    198mm

    P.F

    ≥0.9

    Light Source CRI

    Warm white

    Natural white

    Pure white

    3000±200k

    4000±300k

    6000±300k

    Light Source Luminous flux(lm)

    ≥2500LM

    ≥2650LM

    ≥2750LM

    Lighting CCT

    3000±300k

    4000±300k

    6000±500k

    Lighting LM

    2400±250LM

    2450±250LM

    2550±250LM

    Lighting View Angle

    90°

    Lighting CRI

    ≥70/≥80

    Key point temperature
    (during aging test)

    LED Welding foot

    Lamp shell

    ≤75°C

    ≤70°C

    Working Temp.

    -10°C~40°C / R.H.≤85%

    Storage Temp.

    -30~65°C

    Life span

    50,000 HR

    IP Rate

    IP20


    4.Application

    Offices, shopping mall, supermarket, schools, hospitals, hotels, parking lot, factories, municipal engineering, houses etc.


    Recessed LED down light prices - cob 30w led down light supplyRecessed LED down light prices - cob 30w led down light supply

    5.Payment

    We accept PayPal, T/T, L/C,Western union, Escrow etc .If need further detail, Please feel free to contact us, Thanks!


    Recessed LED down light prices - cob 30w led down light supply

    6.Shipment

    We ship by commercial express,Air freight,Ship.

    Recessed LED down light prices - cob 30w led down light supplyRecessed LED down light prices - cob 30w led down light supply

    7.Packing, transportation & storage requirement

    8.1, Packing Material

    Name

    Description

    QTY

    PE bag

    380*350mm

    1pcs

    /

    20±5g

    White box

    230*230*100mm

    1pcs

    N.W

    1280±30g/1PCS

    Big carton case

    515*475*480mm

    1/20pcs

    G.W

    25.65±0.5kg/carton

    8.2, Pasted Master Carton label on each main mark and side mark, pasted product label on Lights;

    8.3,Seal packing box tight before transport, handle gently, mark product name, quantity etc on carton box;

    8.4,Storage requirement: moisture proof,dust proof, avoid press, avoid tumble, avoid acid and base, avoid direct sunshine and expose;

    8.5,storage expires: One year. exceed the expire time must Re-inspect electricity function before use.
