    15 watt led down light supply / LED downlight factory

    Ask Lasest Price
    Brand Name : Sourcechip
    Model Number : SC-DLI015W01
    Certification : CE, FCC, RoHS
    Price : US $ 14 - 19 / Piece
    Delivery Time : 3-7days for samples,25 working days or more for bulk order
    Payment Terms : We accept PayPal, T/T, L/C,Western union, Escrow etc .If need further detail, Please feel free to co
    Supply Ability : 3000 Piece/Pieces per Day
    • Product Details
    • Company Profile

    15 watt led down light supply / LED downlight factory

    15 watt led down light supply / LED downlight factory

    Dongguan Sourcechip Opto-electrical Tech Co.,Ltd.

    LED Model No.

    SC-DLI015W01-30

    SC-DLI015W01-40

    SC-DLI015W01-60

    Rated power

    15W

    Consume power

    15±1W

    Input Voltage

    AC 100-240V

    Output Voltage

    45-48V

    Input current

    290mA±5%

    Efficiency

    ≥80%

    Cutout:

    120mm

    P.F

    ≥0.50

    Light Source CRI

    Warm white

    Natural white

    Pure white

    3000±200k

    4000±300k

    6000±300k

    Light Source Luminous flux(lm)

    ≥1250LM

    ≥1300LM

    ≥1350LM

    Lighting CCT

    3000±300k

    4000±300k

    6000±500k

    Lighting LM

    1200±100LM

    1240±100LM

    1270±100LM

    Lighting View Angle

    120°

    Lighting CRI

    ≥80

    Key point temperature
    (during aging test)

    LED Welding foot

    Lamp shell

    ≤75°C

    ≤70°C

    Working Temp.

    -10°C~40°C / R.H.≤85%

    Storage Temp.

    -30~65°C

    Life span

    35,000 HR

    IP Rate

    IP40

    15 watt led down light supply / LED downlight factory

    Product Features:

    1.energy-saving and environmental, no ultra-violet, mercury and infrared, conform to ROHS requires

    2.Isolated low voltage constant current driver, over current protection, over voltage protection and output short circuit protection; High safety, stability and reliability;

    3.Adopt import light source and advanced heat dissipation technology, product malfunction life span achieve to 25000 hrs.

    4.Can be frequent starting, no flickering and glaring; high CRI;shock-resistant;

    5.Simple & elegant appearance, newly & attractive design, suit for many illumination places.

    15 watt led down light supply / LED downlight factory

    Product material

    Lamp body

    Diffusive lampshade

    light source

    Driver

    Finish

    aluminium

    lighttransmittance≥85%

    COB

    wide Input driver, EMC approved

    White+black


    15 watt led down light supply / LED downlight factory

    15 watt led down light supply / LED downlight factory

    Application:

    Offices, shopping mall, supermarket, schools, hospitals, hotels, parking lot, factories, municipal engineering, houses etc.

    15 watt led down light supply / LED downlight factory

    Packaging & Shipping

    Packing Material

    Name

    Description

    QTY



    PE bag

    230*210mm

    1pcs

    N.W

    15±5g

    White box

    145*145*50MM

    1pcs

    N.W

    550±30g/1PCS

    Big carton case

    445*445*160MM

    1/27pcs

    G.W

    16±0.5kg/carton

    • Pasted Master Carton label on each main mark and side mark, pasted product label on Lights;
    • Seal packing box tight before transport, handle gently, mark product name, quantity etc on carton box;
    • Storage requirement:moistureproof,dustproof, avoid press, avoid tumble, avoid acid and base, avoid direct sunshine and expose;
    • storage expires: One year. exceed the expire time must Re-inspect electricity function before use.

    15 watt led down light supply / LED downlight factory


    Our Services

    • You inquiry will be replied in 12 hours.
    • All your inquiries will be answered in fluent English by well-trained & professional staffs.
    • We supply OEM & ODM service for our client, natural packing and customer's packing style available without extra cost.
    • Many optional payment terms: L/C, T/T, Western Union, Paypal, Escrow etc, guaranty customer receive high quality products.
    • Many Optional delivery / shipping methods: by ship, by air plane, by commercial express, specific line transportation, by post, etc, guaranty the goods reach customer on time with less freight cost.

    15 watt led down light supply / LED downlight factory
